Motor Extension Cable, 9 Pin Front Rear Wheel Motor Female to Male

Name	Large 9 cores motor cable
Model	WYT-PFV2-916AT
Inlet/Outlet	9 cores
Rated voltage	60V AC/DC
Rated current	power 20A, cable 2A
Withstand voltage	500V
Insulation resistance	≥20MΩ
Contact resistance	≤10mΩ
Mechanical life	200 times
Insertion force	≤100N
Pull out force	≥50N
Working temperature	-25℃～+85℃
Protection grade	IP66
Dimensions	male 16.8mm, female 16mm
Overalllength	88.5mm
Contact element material	gold-plating Copper alloy
Wire specification	2.0mm²+0.20mm²

ATINGS/CHARACTERISTICS

• UL Recognized

• RoHS Compliant

• 48 V

• power 20A, cable 2A

• Waterproof cable: IP65 Sealed waterproof connectors,sturdy and durable

MATERIAL

Water Proof Wire FEATURES

Most common Y splitter connector cable for Electric bike.

Lenght: can be any length needed.

power 20A, cable 2A

Life: 200 times

9PIN

Waterproof cable: IP65 Sealed waterproof connectors,sturdy and durable

WATER PROOF WIRE ENVIRONMENTS

• Ebike motor
