Flat connector 2 Pin waterproof connector 2 pin for e bike electric bike electric bicycle

Name	Flat 2 cores signal cable
Model	WYT-PB-209AT
Inlet/Outlet	2 cores
Rated voltage	48V AC/DC
Rated current	2A
Withstand voltage	250V
Insulation resistance	≥20MΩ
Contact resistance	≤10mΩ
Mechanical life	200 times
Insertion force	≤80N
Pull out force	≥30N
Working temperature	-25℃～+85℃
Protection grade	IP66
Overalllength	51mm
Contact element material	gold-plating Copper alloy
Wire specification	0.20mm²

RATINGS/CHARACTERISTICS

• UL Recognized

• RoHS Compliant

• 48 V

• 2 Pins

•


MATERIAL

FEATURES

Most common signal connector, signal cable for Electric bike.

Lenght: can be any length needed.

Current: 2A

Life: 200 times

ENVIRONMENTS

• Ebike throttle,

• Electric scooter  throttle,

• signal cable,single connector for electric tools
